Boeing 737-287/Adv
- Manufacturer:
- Boeing
- Type / Model:
- 737
- Version:
- 200
- Location:
- Erfurt, Germany
- Photographer:
- Paul Buchroeder
- Date Taken:
- 25/09/2015
- Image ID:
- #233426
- High-Res Photo Dimensions (Pixels):
- 5174 x 3435
- Image Description:
- Former LV-LEB and N768KM(built in 1973) and maintenance trainer by Lufthansa Technical Training in Erfurt until 2015. Here already disassembled and ready for the transportation to Hoofddorp/Netherlands to be a trainer for the MBO College Airport.
Commercial & Editorial Use
For information on this photo or to request a quotation to supply this image as a high resolution file for commercial or editorial purposes.
Buy a Print or Gift
Buy a print, poster or gift of this image for personal or corporate decorative display. Prints are available in a number of sizes and finishes.
Aircraft Data
The B737 is a twin engined short to medium range narrow body airliner. It is the most successful airliner in its class, first delivered in 1967, it has been developed continuously into a family of increasingly capable versions.
The -200 was the main production variant of the Classic 737 being slightly longer than the initial variant, the -100. Had up to 60% structural commonality with the Boeing 727, having 6 abreast seating was a major selling point in a small airliner.
| Country of Origin | First Flight | No. Built | No. In Service | Crew | Passengers |
|---|---|---|---|---|---|
| USA | 1967 | 1114 | 400 | 2 | 97 - 136 |
Power
Typical fit is the JT8D-17 with 16000lb thrust.
| Engine Count | 2 | |
| Engine Variations | ||
| Engine Manufacturer |
|
|
| Engine Name |
|
|
| Engine Class |
|
|
| Engine Power |
|
Dimensions
| Length | 30.53 m. 100 ft. 2 in. |
| Wing Span | 28.35 m. 93 ft. 0 in. |
| Height | 11.28 m. 37 ft. 0 in. |
| Empty Weight | 27512 kg. 60600 lbs. |
| Max Weight | 52437 kg. 115500 lbs. |
Performance
| Max Speed | 819 kph 509 mph |
| Cruise Speed | 740 kph 460 mph |
| Ceiling | 10668 m. 35000 ft. |
| Normal Range | 3519 1900 nm km. |
| Max Range |
4260
2300
nm
km.
Max range could vary according to engines fitted, plus weight options. |
