Panavia Tornado ECR

Manufacturer:
Type/Model:
Registration:
Colour Scheme:
Taken By:
Date Taken:
18th May 2018
Image ID:
433745

Commercial & Editorial Use

For information on this photo or to request a quotation to supply this image as a high resolution file for commercial or editorial purposes.

Aircraft Data

The Tornado was manufactured by Panavia, a consortium of BAE Systems, EADS and Alenia and is operated by the Royal Air Force, German Air Force, Italian Air Force and Royal Saudi Air Force

Tornado GR 1 strike aircraft for close air support; counter air attack. GR 1A tactical reconnaissance aircraft. GR 1B long-range maritime attack aircraft and Tornado F3 long-range air defence fighter. The GR 4 is a mid-life update of the GR 1.

Summary data for Panavia Tornado -
Country of originFirst flightNo. builtNo. in serviceCrewPassengers
United Kingdom; Germany; Italy19749923002n/a

Power

2 x Turbo-Union RB.199 (9100 - 16400 lbf) turbofan engines.


Weapons

Fitted with two 25mm cannons. Hardpoints: Four fuselage pylons and four swivelling under-wing pylons with a capacity of 19,800 lb for a wide variety of weapons, fuel and EM Pods.


Dimensions

Dimensions for Panavia Tornado -
Length54 ft. 10 in.
Wing Span28 ft. 2 in. - 45 ft. 6 in. (at 67° wing sweep)
Height19 ft. 6 in.
Empty Weight31,620 lbs.
Max Weight61,700 lbs.

Performance

Performance of Panavia Tornado -
Max Speed1,511 mph
Cruise Speed1,000 mph
Ceiling50,000 ft.
Normal Range870mi. (typical combat mission)
Max Range2,417mi. (with 4 external drop tanks)

Updated 9th February 2009
